ENGINEERED TO MEET YOUR NEEDS
At Atlas Copco we aim to provide you with compressors that fulfil and even exceed your expectations and demands. Built as the result of decades of experience in oil-free design and manufacturing, the AQ range of oil-free screw compressors gives you all of this experience and knowledge in a class leading package.
Water-injected screw element
• Highly energy-efficient thanks to low temperatures.
• Water-lubricated, grease-free bearings.
• In-house design and manufacturing.
• Working pressure up to 13 bar.
Water filter
• Ensuring a constant supply of clean water.
• The filtration capability equals 10 micron
throughout the filter’s lifetime.
Heavy-duty air filter
• Protects the compressor components by removing 99.9% of dirt particles down to 3 microns.
• Differential inlet pressure for proactive maintenance while minimizing pressure drop.
Separator vessel
• Stainless steel water separator vessel for separation via centrifugal and gravity forces.
• Three sensors included for precise water regulation.
Induction motor
• IP55 induction motor, flange-mounted for perfect alignment.
• Combined with direct driven arrangement for superior energy efficiency.
Reverse osmosis system
The built-in reverse osmosis system provides a reliable supply of high quality water, ensuring autonomy and continuous operation.
Air-cooled fan and water-cooler
• Air and water-cooled variants are available throughout the range.
• Small footprint and installation thanks to built-in heat exchangers.
• Water-cooled units provide a continuous air temperature at the dryer inlet of less than 55°C (131°F).
Integrated highly efficient dryer
• Excellence in air quality.
• 50% reduction in energy consumption compared to traditional dryers.
• Zero ozone depletion.
Sound insulated canopy
No separate compressor room is required as the sound insulated canopy allows for installation in most working environments.
Electronic no-loss water drain
• Ensures constant removal of condensate.
• Manual integrated bypass for effective condensate removal in case of power failure.
• Integrated with compressor’s Elektronikon® with warning/alarm features.
